VC500-BTS｜Intel®｜Industrial Computers｜DFI

VC500-BTS
Overview
Overview
Specification
Download
QUOTE
2
COMPARE
Home Application-Specific System In-vehicle System VC500-BTS
  • Intel Core Series 2 Processors with P-cores
  • 16x 802.3af/at PoE ports, Max 120W
  • AI accelerated: up to 115W GPU MXM module supported
  • Multiple expansion slots for 5G cellular supported
  • Extended operating temperature: -20°C to 70°C

Status : Preliminary QUOTE NOW

Wide-temp: -20~70°C
Multiple Expansion
5G
PoE LAN
AI
+Compare +Quotation
Product Comparison
You have items. ,Up to 3 items.
COMPARE NOW
Quotation
You have ,Up to 3 items.
QUOTE NOW
RoHS Certification
CE Certification
FCC Certification
UKCA Certification
E-Mark (E24) Certification

VC500-BTS Related Tags

#DDR5#Edge AI Computing#USB Type-C DP#E-Mark (E24) Certification#Intel Core Series 2 Processors with P-cores#MXM#IoT#AI#Intel#5G#PoE#CAN-Bus#Mini PCIe#Fanless Design#4K2K Display#1G Ethernet#Windows#Linux#HDMI#DP#Multiple Expansion#RoHS Certification#CE Certification#FCC Certification#In-Vehicle#High-Performance#UKCA Certification
VC500-BTS｜Intel®｜Industrial Computers｜DFI
VC500-BTS｜Intel®｜Industrial Computers｜DFI

Related Products:

Select All - Clear
System
Processor
Intel Core Series 2 Processors with P-cores
Intel® Core™ 9-273PE (12 (12+0) cores, 36M cache, up to 5.7GHz); 65W
Intel® Core™ 7-253PE (10 (10+0) cores, 33M cache, up to 5.5 GHz); 65W
Intel® Core™ 5-223PE (8 (8+0) cores, 24M cache, up to 5.4 GHz); 65W
Intel® Core™ 9-273PTE (12 (12+0) cores, 36M cache, up to 5.5 GHz); 45W
Intel® Core™ 7-253PTE (10 (10+0) cores, 33M Cache, up to 5.4 GHz); 45W
Intel® Core™ 5-223PTE (8 Cores, 24M Cache, up to 5.4 GHz); 45W
Chipset
Intel® R680E Chipset
Memory
Dual Channel DDR5 up to 5600 SDRAM, up to 64GBy SODIMMs up to 64GB
BIOS
AMI SPI 128Mbit
Graphics
Controller
Intel CPU integrated graphics
Display
1 x HDMI 1.4b, resolution up to 4096x2160 @ 24Hz
2 x DP++, resolution up to 4096x2304 @ 60Hz
1 x USB type C (DP Alt. mode), resolution up to 4096x2304 @ 60Hz
Storage
External
2 x Swappable 2.5” storage bays with lock, 2x 4-pin 2.5mm wafer connector for SATA power
Expansion
Interface
1 x Full Size Mini PCIE slot, PCIe x1, USB 2.0 signal for GNSS or CAN bus, support 1x internal Nano SIM
2 x M.2 Slot, 2230,A+E Key, PCIe x1, USB 2.0 signal for Wifi/BT Modules
1 x M.2 Slot, 2230,A Key, 2 x UART, 2 x I2C, 1 x USB2.0, 1 x SPI, DFI OOB module
1 x M.2 slot, 2280,B+M-key, PCIe Gen3 x4, SATA signal
1 x M.2 Slot, 3042/3052, B+M key, PCIex1, USB3.0, USB2.0 for 5G/4G modules, support 2x Nano SIM
Audio
Audio Codec
Realtek ALC888
Interface
1 x Line-out, 1 x Mic-in with 3.5mm audio tower
LED
Indicators
1 x Storage Activity (Red)
1 x Power (Green)
8 x PoE LAN Activity link (Yellow) within RJ45
8 x PoE Enable (Green) within RJ45
8 x PoE LAN Active link (Red) for M12
8 x PoE Enable (Green) for M12
2 x Programmable general purpose (Green, Blue)
Front I/O
PoE
16 x GbE LAN, RJ45 with PoE 802.11af/at ports, max. 120W
Serial
2 x RS232 ports, DB-9
USB
1 x USB 3.2 Gen1 Type A (Vertical)
1 x USB Type C (DP Alt mode)
2 x USB 3.2 Gen1 Type A
Display
4 x DP from MXM
Audio
1 x Line-out, 1 x Mic-in with 3.5mm audio tower
DIO
1 x 8bit isolated DI port, DB-9
1 x 8bit isolated DO port, DB-9, 2KV isolation
CANBus
2 x CAN bus, DB-9 (option), Support J1939
Rear I/O
DIO
2x Isolated DIO port, terminal block
Supports 16bit DIO with 2.5KV isolation
Display
1 x HDMI, Resolution up to 4096x2160 @ 24Hz
2 x DP++, Resolution up to 4096x2304@60Hz
Buttons
1 x Power Button
1 x Reset Button
Antenna
7 x antenna holes, 5G x4, GNSS x1, Wifi x2
SIM
2 x SIM slots with cover bracket
Power
Wide Range 9~50VDC with power management (on/off delay) and ignition
SSD
2 x 2.5'' SSD Drive bays
OS Support
Microsoft
Windows 11 IoT Enterprise LTSC SW
Linux
Ubuntu 24.04
Environment
Operating Temperature
-25°C to 70°C (Max. by model)
Storage Temperature
-40 to 85°C
Relative Humidity
10% to 90% (non-condensing)
Mechanism
Construction
Aluminum + SPGC Metal
IP Rating
IP40
Mounting
Wall mount
Dimensions (W x H x D)
308 mm x 97.88 mm x 222.3 mm (w/o MXM)
409 mm x 97.88 mm x 222.3 mm (w/ MXM)
Weight
9.85 kg
Standards and Certifications
Shock
(SSD/HDD) MIL-STD-810G
Vibration
MIL-STD-810G
Certifications
CE, FCC, E-Mark , RoHS, UKCA Compliant
Country of Origin
Country of Origin
Taiwan
